Nickel Coated N45M Neodymium Magnet Disc

Nickel Coated N45M Neodymium Magnet Disc
Similar Products
  • Magnetic Disc 1 inch x 1 inch N42 Neodymium Disc Magnets Cylinder
    Magnetic Disc 1 inch x 1 inch N42 Neodymium Disc Magnets Cylinder SKU Code: ATECHDI024 Dimensions: D1 ""x /8"" Thick Tolerances: ±0.05mmMaterial: NdFeB, Grade N42Plating/Coating: Ni-Cu-NiMagnetization Direction: AxialWeight: 50 gBr Max/Gauss rating: 13200 GSMax Ope...
  • Industrial Magnet N52 3/8”
    Industrial Magnet N52 3/8” SKU Code: ATECHDI004 Dimensions: D3/8""x1/8"" Thick Tolerances: ±0.05mmMaterial: NdFeB, Grade N52Plating/Coating: Ni-Cu-NiMagnetization Direction: AxialWeight: 0.6 gBr Max/Gauss rating: 14800 GSMax ...
  • Nickel Coated N45M Neodymium Magnet Cylinder
    Nickel Coated N45M Neodymium Magnet Cylinder MaterialNdFeBGradeN45MRemanence Br(kGs)Max:13.8Min:13.2PlatingNi-Cu-Ni (Nickel)ShapeCylinderCoercive force(kOe) Min.12.5Intrinsic Coercive force (kOe) Min.14Max energy product (MGOe)Max:46Min:43Max Temp (℃)...
Nickel Coated N45M Neodymium Magnet Disc is made from high performance Neodymium Iron Boron. The NORTH pole is on one circular face and the SOUTH pole is on the opposite face. These Magnets are plated with 3 layers of protective coatings - Nickel + Copper + Nickel (Ni-Cu-Ni). The maximum operating temperature of Nickel Coated N45M Neodymium Magnet Disc is up to 100 degrees C.

Material NdFeB
Grade N45M
Remanence Br(kGs) Max:13.8
Min:13.2
Plating Ni-Cu-Ni (Nickel)
Shape Disc
Coercive force(kOe) Min. 12.5
Intrinsic Coercive force (kOe) Min. 14
Max energy product (MGOe) Max:46
Min:43
Max Temp  (℃) 100
